Lab Ball Mill
Super Fine Powder Grinding Technic

Application & Process :

The Laboratory scale Ball Mill is mainly used for various grind able materials dry or wet type in Chemical, Pharmaceuticals, Herbals and Catalyst Industries for super fine micron size grinding

Prism Laboratory Scale Ball Mill is made from all the contact parts in S.S.316 & non contact parts in S.S. 304.The Drum Size: Dia 90 x 90 mm length cylinder type made from S.S.304 Quality. The drum is rotate on two nos. drive shaft and the shaft is rubber coated. The drum is having variable speed through Ac frequency drive for up to 60 RPM. The complete drive unit with motor and gear box is enclosed in structure and it is made from S.S.304Q. The Controls panel provided with ON-OFF push button, Speed regulator, RPM Meter and Process Cycle timer.

New Design Features :

  • Design as per stringent GMP Model.
  • Contact parts of SS 316 and non contact parts of SS 304.
  • Variable speed for drum up to 60 RPM.
  • Drive shaft with rubber coating.
  • RPM Indicator and Cycle Timer.
MODEL
PBM-1
Capacity
1 kg
Drum Diameter
90 mm
Total Electric Power
0.18Kw
Drum Speed
Variable
